CRE Technology GENSYS 2.0 User Manual

A53 Z0 9 0020 L En Technical documentation
Chapter : I/O lines
103
Ohm
VDO 120°
VDO 150°
Veglia
Datcon L
Datcon H
AC
0
145
1000
1000
1000
0
1000
40
96
119
140
104
40
104
80
74
94
118
78
80
78
120
63
80
105
63
120
63
160
55
70
96
52
160
52
200
49
62
89
43
200
43
240
44
56
83
36
240
36
280
40
51
78
31
280
31
320
37
46
74
26
320
26
360
34
42
70
21
360
21
400
32
38
67
17
400
17
Table 33 - Water Temp calibration points
2/ Engine measurements 1 and 2
Spare 1 engine measure calibration points are [E1210 to E1220].
Spare 1 engine measure impedance points are [E1188 to E1198].
Spare 2 engine measure calibration points are [E1232 to E1242].
Spare 2 engine measure impedance points are [E1199 to E1209].
For each of the two spare sensors, this table shows the given value (left side) for each of ten sampled
resistive values in ohms (right side). Intermediate values are obtained with linear approximation.
E. g.: min = 3000, max =6000, gives the values corresponding to 3000, 3300, 3600, 3900, 4200, 4500,
4800,..., 5700, 6000 Ohms. These can be used in equations or displayed.
11.3.5 Use spare analogue input as digital input
If necessary, it is possible to use an analogue input as a digital input.
1/ Purpose
Use spare analogue input (spare 1 and 2, connections F1-F2 and F3-F4) as digital input.
2/ Configuration
Spare analogue input calibration table should be set as shown below to mimic digital input.
