A53 Z0 9 0020 L En Technical documentation
17.3.4
Engine
Internal start sequence
[0]
The start sequence is managed by the GENSYS 2.0 (See §7
for more details)
External Auto start
module [1]
The start sequence is managed by an external module
(See §13.5 for more details)
Table 90 – External/internal start sequence configuration
Crank settings
This menu is showed only if an internal start sequence has been selected. It allows to set the following
parameters :
Number of start attempts.
Num of starter
[E1138]
(1)
The speed (RPM) above which the engine is considered to be
started for crank 1.
Sta.2 drop out
[E1325]
(1)
The speed (RPM) above which the engine is considered to be
started for crank 2.
Sta.3 drop out
[E1325]
(1)
The speed (RPM) above which the engine is considered to be
started for crank 3.
Table 91 - Configuration reglages démarreur
(1) Only available on level 2
Checking before starting
This menu is showed only if an internal start sequence has been selected.
Pre-heat is activated if J5 is closed and if temperature is under the
preset threshold (E0030 < E1154)
Pre-lubrication will be activated when engine state is “pre-start”
and if pressure is under the threshold (E0029 < E1155). If the
threshold [E1155] is 0, then pre-lubrication is active while the
engine state is “pre-start”. In this case, an oil pressure sensor isn’t
required
Cooling thresh
[E1178]
(1)
Air fan is activated when temperature is over the preset threshold
[E1178] and deactivated when water temperature is lower than
80% of the threshold. Air fan is not active when engine is stopped.
Table 92 – Checking before starting configuration
(1) Only available on level 2
