A53 Z0 9 0020 L En Technical documentation
Chapter : Text file & PLC
{PARAMETERS}
V1006 320 Y Gen nominal kW +00000 +65535
V1007 1.00 N Gen PT ratio +00000 +65535
In the example above, Genset nominal power is set to 320kW. The Y attribute shows that this value can be
changed by MODBUS or custom PLC equations whereas the N attribute in the second line sets Generator
PT ratio as "read only" for MODBUS and PLC equations.
Note: This attribute can only be changed when using access level 2.
It is possible to modify the values directly in the text file before uploading it into the module. The user must
be sure that the modified value is within the minimum / maximum range of the parameter. Failure to do so
will lead to an error message during uploading (Compilation result: VARIABLE).
It is also possible to write an incomplete parameter block (not all parameters are displayed in the list).
When uploaded, such a file will only modify the parameters which have been entered, the others remain
unchanged. This procedure can be used to upload an old text file into a newer module or to activate special
features independently.
14.3.3
Label definition block
The beginning of this block is shown by a "{LABELS}" statement.
This block is used to define custom labels.
Only the spare analogue inputs, the digital inputs, the virtual digital inputs, the maintenance cycle, and the
lines in the Logo Page can have an input in this block. The table below shows the correspondence between
the LABEL number and its associated value:
L0029 AI oil press.
L0030 AI water temp.
L0031 AI spare 1
L0032 AI spare 2
L1442 Cycle 1 (h)
L1443 Cycle 2 (h)
L1444 Cycle 3 (h)
L1445 Cycle 4 (h)
L1446 Cycle 5 (h)
L1447 Cycle 1 (d)
L1448 Cycle 2 (d)
L1449 Cycle 3 (d)
L1450 Cycle 4 (d)
L1451 Cycle 5 (d)
L2283 Virtual in 1
L2284 Virtual in 2
L2285 Virtual in 3
L2286 Virtual in 4
L2287 Virtual in 5
L2288 Virtual in 6
L2289 Virtual in 7
L2290 Virtual in 8
L2291 Virtual in 9
L2292 Virtual in 10
L2293 Virtual in 11
L2294 Virtual in 12
L2295 Virtual in 13
L2296 Virtual in 14
L2297 Virtual in 15
L2298 Virtual in 16
L2299 Virtual in 17
L2300 Virtual in 18
L2301 Virtual in 19
L2302 Virtual in 20
L2565 Virtual in 21
L2566 Virtual in 22
L2567 Virtual in 23
L2568 Virtual in 24
L2569 Virtual in 25
L2570 Virtual in 26
L2571 Virtual in 27
L2572 Virtual in 28
L2573 Virtual in 29
L2574 Virtual in 30
L2575 Virtual in 31
L2576 Virtual in 32
L2577 Virtual in 33
L2578 Virtual in 34
L2579 Virtual in 35
L2580 Virtual in 36
L2581 Virtual in 37
L2582 Virtual in 38
L2583 Virtual in 39
L2584 Virtual in 40
L2657 User meter 1
L2659 User meter 2
L2804 Oil Pres/In J4
L2805 Wat.Temp/In J5
L2806 Spare Input J6
L2807 Spare Input J7
L2808 Spare Input J8
L2809 Spare Input J9
L2810 Spare InputJ10
L2811 Spare InputJ11
L2812 Spare InputJ12
L2813 Spare InputJ13
L2814 Spare InputJ14
L2815 Spare InputJ15
Table 46 - Label definition bloc
