Validity
Virtual input validity variable numbers: [E1348 to E1357 / E1388 to E1397 / E1640 to E1659] can be set as:
Never [E2329]: never active: should be selected if you do not use the input.
Always [E2330]: always active: input will be monitored as long as GENSYS 2.0 has power supply.
Post-Starting [E2192]: the input will be monitored at the end of the "safety on" timer.
Stabilized [E2331]: The input will be monitored when genset frequency and voltage are stable.
Spare scenario: [E2332]: input will be monitored as programmed in equations.
Direction
Virtual input direction variable numbers: [E1358 to E1367 / E1398 to E1407 / E1659 to E1679]. Can be set
as:
NO [0]: normally open; should be selected unless the input is used for protection.
NC [1]: normally closed. This should be selected if the input is normally connected to 0V and opens
when active.
Accuracy
This parameter sets accuracy (number of digits after decimal point). Possible values are:
1
0.1
0.01
0.001
Functions
Virtual input function variable numbers: [E1328 to E1337 / E1368 to E1377 / E1680 to E1699] can be set as
described in chapter §11.1.5.
Note : Both virtual and real inputs use the same functions.
17.3.7
Outputs
1/ Digital outputs
This menu allows to configure the digital outputs (C1 to C5).
For each digital output, the settings are:
Function :
The function associated to the digital output.
For more details on the available functions, see chapter §11.2.1.
Polarity :
NE: normally energised; the output will de-energize when required, depending on its function.
ND: normally de-energized; the output will energize when required.
Table 100 – Digital outputs configuration
2/ Relay outputs
The "Crank" and "Fuel" relay (output A1 and A2 respectively) can be configured to other functions.
