CRE Technology GENSYS 2.0 User Manual

A53 Z0 9 0020 L En Technical documentation
Chapter : Additional functions
119
13.7 Safety Inhibitions
13.7.1 Objective
Safety inhibitions are mandatory on certain types of application, particularly in safety
generators used in public spaces (norm NF E 37-312).
The aim is to inhibit the oil pressure and water temperature safeties on the GENSYS 2.0.
Thus, in the case of a fault, the generator remains in operation. Other protections (over
speed, overload, etc...) are still active if set.
13.7.2 Configuration
1/ Hardware
Contacts for oil pressure and water temperature are no longer connected to J4 and J5 but to spare
configurable inputs.
In this example, the oil pressure and water temperature contacts are on J13 and J14.
2/ Software
The following equations must be downloaded to level 1 or 2 (as described in §15.7.3 or §17.4.7):
