CRE Technology GENSYS 2.0 - Table 84 - Generator ½ Configuration; Table 85 - Generator 2;2 Configuration

A53 Z0 9 0020 L En Technical documentation
Chapter : Menu overview
208
17.3.2 Generator
1/ Generator ½
Parameter
[var.num]
comment
Nominal kW
[E1006]
Nominal power of the generator.
Nominal kVAR
[E1015]
Nominal reactive power of the generator.
Nominal Volt
[E1107]
Voltage setpoint.
Nominal kW 2
[E1607]
(1)
Second nominal power of the generator, activated with logical
input or equations.
Nominal kVAR 2
[E1636]
(1)
Second nominal reactive power of the generator, activated with
logical input or equations.
Nominal Volt 2
[E1108]
(1)
Second voltage setpoint, activated with logical input or equations.
PT ratio
[E1007]
Ratio of the voltage transformers (Ex: 20 kV to 100 V: type in 200).
CT ratio
[E1008]
Ratio of the current transformers (Ex: 100A to 5A: type in 20).
Maximum ratio is 3250 (soit 3250:1 ou 16250:5).
cos(φ) setpoint
[E1110]
(1)
Power factor set point when running parallel to the mains.
Table 84 – Generator ½ Configuration
(1) Only available on level 2
2/ Generator 2/2
Parameter
[var.num]
comment
kW low lim
[E1091]
Lower power limit of the genset; enter a value (in kW) that will
prevent reverse power protection triggering.
kW high lim
[E1092]
Upper power limit of the genset; enter a value (in kW).
Base load kW
[E1093]
Generator kW set point in constant production mode.
Base load kW 2
[E1094]
(1)
Second generator kW set point in constant production mode,
activated with logical input or equations.
Load ramp
[E1151]
Time to ramp up from lower limit [E1091] to nominal kW [E1006].
Unload ramp
[E1152]
Time to ramp down from nominal kW [E1006] to lower power limit
[E1091].
Table 85 - Generator 2/2 Configuration
(1) Only available on level 2
