A53 Z0 9 0020 L En Technical documentation
Chapter : Predefined configuration
8.5
Multiple generators with static paralleling
This mode is useful when you urgently need to start a full plant with multiple generators. The generators
will be ready to take load in the shortest possible time.
This mode is also very useful when your installation includes high voltage transformers. Starting generators
which are paralleled together gives a progressive magnetization without peaks (no transient short-circuit).
Note: As long as there is a voltage on the bus bar, the dynamic paralleling mode will be used even if static
paralleling is configured. The static paralleling mode is only usable if all of the power generators are
stopped and bus bars are dead.
Figure 23 - Static paralleling with 4 generators coupled together in emergency situation
8.5.1
Sequence
Figure 24 - Example with 4 generators paralleled together in emergency situation.
