A53 Z0 9 0020 L En Technical documentation
Chapter : Menu overview
206
17.3.1
Power plant
Parameter
[var.num]
Possible value
Comment
My number
[E1179]
1 to 32
Is the number given to this particular GENSYS 2.0 on the
power plant.
Quantit.GENSYS
[E1147]
1 to 32
Is the total number of GENSYS 2.0 installed on the power
plant.
Quantit.MASTER
[E4006]
0 to 32
Is the total number of MASTER 2.0 (Mains control modules)
installed on the power plant.
Mains parallel
[E1148]
ChangeOver [0]
On Mains failure, engine starts and takes the load by
opening mains breaker and closing genset breaker with
interlocking. On mains return, unload genset by opening
genset breaker and closing mains breaker with interlocking,
and stop engine.
NoBreak CO [1]
Only available with mains paralleling option
Same as changeover mode but loading/unloading is made
without black, with ramps after synchronization with mains.
Permanent [2]
Only available with mains paralleling option
after a start demand, GENSYS 2.0 will synchronize genset to
mains and keep both breakers closed.
No ch.over [3]
GENSYS 2.0 must receive a start demand and will not
manage mains breaker output. There will be no
synchronization with the bus bar or the mains.
Load sharing
[E1158]
Analog[0]
Load sharing will be done via analog bus (pins G4 and G6).
CAN bus[1]
Load sharing will be done via inter GENSYS digital CAN bus
(COM 2 port).
Mains regul.
[E1153]
Peak shav.[1]
GENSYS 2.0 will permanently vary genset power to maintain
constant power supply from mains.
Base load[2]
GENSYS 2.0 will permanently maintain constant genset
power.
Static parallel
[E1177]
(1)
No[0]
Standard synchronization: will be carried out by adjusting
engine speed and generator voltage.
Yes[1]
Breakers are closed before engine starting and generator
excitation.
Deadbus manag.
[E1515]
Yes[0]
Dead bus management will be done via inter GENSYS digital
CAN bus (COM2 port).
No[1]
External logic controls dead bus management.
Voltage schema
[E4039]
Triphase 120° [0]
Voltage system selection (See §13.17 for more details)
Biphase 180° [1]
Monophase [3]
Table 81 Power plant configuration
(1) Only available on level 2
