CRE Technology GENSYS 2.0 User Manual

A53 Z0 9 0020 L En Technical documentation
Chapter : Text file & PLC
144
{UNITS}
U0029 01
U2584 00
A0029 0000032768
The tables below give you the list of codes which correspond to the supported units and accuracies. In the
examples above, input E2584 has no specific unit while input E0029 will be displayed in Volts (Unit code 01)
and with 2 decimal digits (Accuracy code 32768).
Code
Accuracy
00000
1
16384
0.1
32768
0.01
49152
0.001
Table 48 - Accuracy codes
Code
Unit
Code
Unit
Code
Unit
Code
Unit
Code
Unit
Electrical
Power
Pressure
Volume
Time
00
“ “
07
kW
13
Bar
20
L
24
s
01
V
08
kWh
14
mBar
21
m3
25
h
02
kV
09
kVAR
15
kPa
22
mm3
26
days
03
mA
10
kVARh
16
PSI
23
Gal
Time related
04
A
Rotating speed
Temperature
27
Hz/s
05
kA
11
rpm
17
°
28
m3/h
Frequency
Percent
18
°C
29
L/h
06
Hz
12
%
19
°F
30
Gal/h
Table 49 – Units codes
Code Variable
number
Default
unit code
Default
accuracy code
Description
Label
Native analogue inputs
0029
14
00000
Analogue measure of oil pressure (0-
400Ω)
AI oil press.
0030
18
00000
Analogue measure of water temp (0-
400Ω)
AI water temp.
0031
00
00000
Analogue measure of analogue 1 (0-
10kΩ)
AI spare 1
0032
00
00000
Analogue measure of analogue 2 (0-
10kΩ)
AI spare 2
Analogue inputs for CANopen extensions
0285
00
16384
analogue input 1
Analog in 01
0286
00
16384
analogue input 2
Analog in 02
0287
00
16384
analogue input 3
Analog in 03
0288
00
16384
analogue input 4
Analog in 04
