A53 Z0 9 0020 L En Technical documentation

Chapter : Predefined configuration

Figure 27 - Typical sequence in No Break CO mode on mains failure

T1 : Fastest mains failure

T2 : Switch over delay [E1459]

T3 : Genset ready

T4 : Mains back delay [E1085]

T5 : Synchronization

T6 : Unload ramp

Ramp configurations are available in the “Configuration / Generator” menu. The paralleling time depends

on the load, the ramp time and the high and low thresholds.

Black

E2201(Mains failure)

E2000 (Mains breaker)

E0003 (Genset voltage)

E2001 (Genset breaker)

E0022 (Mains voltage)
