A53 Z0 9 0020 L En Technical documentation

Chapter : Communication

172

Measure

PGN

(1)

SPN

(2)

Description

ACTUAL_TORQUE

[E2852]

0xF004

513

The calculated output torque of the

engine. The data is transmitted in

indicated torque as a percent of

reference engine torque

DD_TORQUE

[E2851]

0xF004

512

The requested torque output of the

engine by the driver. It isbased on input

from the following requestors external

to the powertrain: operator (via the

accelerator pedal),cruise control and/or

road speed limit governor

MTU_CODE_ERREUR

[E2839]

0xFF04

MTU error codes. (not use for

protection)

Table 65 – J1939: Measurement list

(1) PGN : Parameter Group Number

(2) SPN : Suspect Parameter Number
