CRE Technology GENSYS 2.0 User Manual

A53 Z0 9 0020 L En Technical documentation
Chapter : Menu overview
222
Hz loop
This menu is only availble in level2. It allows to set the center frequency PID (See §13.1 for more details)
Parameter
[var.num]
Comment
G
[E1902]
Global gain of the center frequency
Table 109 - PID Hz loop configuration
While you adjust the PID settings, the following parameters are displayed:
 Generator active and reactive power (P et Q),
 Engine speed,
 Generator voltage (phase 1),
 Frequency,
 Sum of the speed output (en %).
2/ kVAR control
kVAR sharing loop
When reactive load sharing is enable, this menu allows to set the kVAR sharing PID. (See §13.12 for more
details on PID)
Parameter
[var.num]
Comment
G
[E1123]
Global gain of the reactive load sharing
Table 110 - PID kVAR sharing loop
While you adjust the PID settings, the following parameters are displayed:
 Generator active and reactive power (P et Q),
 Engine speed,
 Generator voltage (phase 1),
 Reactive power set point,
 3 phases reactive load.
cos(φ) loop
This menu allows to set the cos(φ) control when the generator is paralleled with mains. (See §13.12 for
more details on PID)
Parameter
[var.num]
Comment
G
[E1119]
Global gain of cos(φ) control
I
[E1121]
Integral of cos(φ) control
Table 111 - PID cos( φ ) loop configuration
While you adjust the PID settings, the following parameters are displayed:
 Generator active and reactive power (P et Q),
 Engine speed,
 cos(φ) setpoint,
 cos(φ) by phase (1, 2 and 3),
