Custom data received from other modules
Only for modules with firmware v4.00 and above
Table 57 - Broadcast data received from inter module CAN bus
Note: Even if CAN bus inhibition is activated between GENSYS 2.0 units (see chapter below), broadcast data
is always sent to the CAN bus and received on the other units.
Analogue and digital data broadcast example
In this example, two GENSYS 2.0 are connected together using CAN bus COM1. Both units (GENSYS 2.0 #1
and GENSYS 2.0 #2) send two broadcast variables to each other on the CAN bus, one variable being digital
input J6 (E2806) and the other one being analogue value E0033 (engine speed).
