Chapter : Additional functions
120
BLOC
@***************************************************************;
@ Oil pressure and water temp Inhibition ;
@***************************************************************;
@E2811 Logical Input J11 GENSYS 2.0 inhibit security ;
@E2812 spare input 8 J12 oil pressure ;
@E2813 spare input 9 J13 is water temperature ;
@E1273 fct spare input J12 ;
@E1274 fct spare input J13 ;
@E0033 speed ;
@E1712 user param: start speed ;
@E1714 user param: stop speed ;
@E1456 Oil pressure sign ;
@E1457 Water temp sign ;
@E2283 Virtual input 1 alarms inhibition ;
@***************************************************************;
TEST E2011 EQ 1 THEN
BLOC
E1457:=0;
E2283:=1;
E1274:=2208;
TEST E0033 GT E1712 THEN E1456:=0
ELIF E0033 LE E1714 THEN E1456:=1
TEND;
E1273:=2208
BEND
ELSE
BLOC
E1456:=E2812;
E1457:=!E2813;
E2283:=0;
E1273:=1;
E1274:=1
BEND
TEND
BEND
