Virtual Router Redundancy Protocol (VRRP) | 1105
Figure 55-8. Command Example Display: show vrrp
Configure VRRP Authentication
Simple authentication of VRRP packets ensures that only trusted routers participate in VRRP processes.
When authentication is enabled, FTOS includes the password in its VRRP transmission, and the receiving
router uses that password to verify the transmission.
Configure simple authentication with the following command in the VRRP mode:
Note: All virtual routers in the VRRP group must be configured the same: authentication must be enabled
with the same password or authentication is disabled.
Task Command Syntax Command Mode
Configure a simple text password.
authentication-type simple
[encryption-type] password
Parameters:
encryption-type: 0 indicates unencrypted; 7
indicates encrypted
password: plain text
INTERFACE-VRID
FTOSshow vrrp
------------------
GigabitEthernet 1/1, VRID: 111, Net: 10.10.10.1
State: Master, Priority: 255, Master: 10.10.10.1 (local)
Hold Down: 0 sec, Preempt: TRUE, AdvInt: 1 sec
Adv rcvd: 0, Bad pkts rcvd: 0, Adv sent: 2343, Gratuitous ARP sent: 5
Virtual MAC address:
00:00:5e:00:01:6f
Virtual IP address:
10.10.10.1 10.10.10.2 10.10.10.3 10.10.10.10
Authentication: (none)
------------------
GigabitEthernet 1/2, VRID: 111, Net: 10.10.2.1
State: Master, Priority: 125, Master: 10.10.2.1 (local)
Hold Down: 0 sec, Preempt: TRUE, AdvInt: 1 sec
Adv rcvd: 0, Bad pkts rcvd: 0, Adv sent: 601, Gratuitous ARP sent: 2
Virtual MAC address:
00:00:5e:00:01:6f
Virtual IP address:
10.10.2.2 10.10.2.3
Authentication: (none)
FTOS(conf)#
