Dell Force10 S4810P - Enable Rip Globally

Routing Information Protocol (RIP) | 845
• Control route metrics on page 851 (optional)
• Summarize routes on page 850 (optional)
• Control route metrics on page 851
• Debug RIP on page 851
For a complete listing of all commands related to RIP, refer to the
FTOS Command Reference.
Enable RIP globally
By default, RIP is not enabled in FTOS. To enable RIP, use the following commands in sequence, starting
in the CONFIGURATION mode:
After designating networks with which the system is to exchange RIP information, ensure that all devices
on that network are configured to exchange RIP information.
The FTOS default is to send RIPv1, and to receive RIPv1 and RIPv2. To change the RIP version globally,
use the
version command in the ROUTER RIP mode.
When RIP is enabled, you can view the global RIP configuration by using the
show running-config
command in the EXEC mode or the
show config command shown in the following example in the
ROUTER RIP mode.
Figure 40-1. show config Command Example in ROUTER RIP mode
When the RIP process has learned the RIP routes, use the show ip rip database command in the EXEC
mode to view those routes as shown in the following example.
Step Command Syntax Command Mode Purpose
1
router rip
CONFIGURATION Enter ROUTER RIP mode and enable the RIP process
on FTOS.
2
network ip-address ROUTER RIP Assign an IP network address as a RIP network to
exchange routing information.
You can use this command multiple times to exchange
RIP information with as many RIP networks as you
want.
FTOS(conf-router_rip)#show config
!
router rip
network 10.0.0.0
FTOS(conf-router_rip)#
