92 | 802.1X
www.dell.com | support.dell.com
no ip address
dot1x authentication
no shutdown
!
FTOS#
View 802.1X configuration information for an interface using the command show dot1x interface, as
shown in the example below.
FTOS#show dot1x interface TenGigabitEthernet 2/1
802.1x information on Te 2/1:
-----------------------------
Dot1x Status: Enable
Port Control: AUTO
Port Auth Status: UNAUTHORIZED
Re-Authentication: Disable
Untagged VLAN id: None
Guest VLAN: Disable
Guest VLAN id: NONE
Auth-Fail VLAN: Disable
Auth-Fail VLAN id: NONE
Auth-Fail Max-Attempts: NONE
Mac-Auth-Bypass: Disable
Mac-Auth-Bypass Only: Disable
Tx Period: 30 seconds
Quiet Period: 60 seconds
ReAuth Max: 2
Supplicant Timeout: 30 seconds
Server Timeout: 30 seconds
Re-Auth Interval: 3600 seconds
Max-EAP-Req: 2
Host Mode: SINGLE_HOST
Auth PAE State: Initialize
Backend State: Initialize
Configuring Request Identity Re-transmissions
If the authenticator sends a Request Identity frame, but the supplicant does not respond, the authenticator
waits 30 seconds and then re-transmits the frame. The amount of time that the authenticator waits before
re-transmitting and the maximum number of times that the authenticator re-transmits are configurable.
Note: There are several reasons why the supplicant might fail to respond; the supplicant might have been
booting when the request arrived, or there might be a physical layer problem.
