Routing Information Protocol (RIP) | 853
Configuring RIPv2 on Core 2
Figure 40-8. Configuring RIPv2 on Core 2
Core 2 Output
The screenshots in this section are:
• Figure 40-9: Using
show ip rip database command to display Core 2 RIP database
• Figure 40-10: Using
show ip route command to display Core 2 RIP setup
• Figure 40-11: Using
show ip protocols command to display Core 2 RIP activity
Figure 40-9. Example of RIP Configuration Response from Core 2
Core2(conf-if-gi-2/31)#
Core2(conf-if-gi-2/31)#router rip
Core2(conf-router_rip)#ver 2
Core2(conf-router_rip)#network 10.200.10.0
Core2(conf-router_rip)#network 10.300.10.0
Core2(conf-router_rip)#network 10.11.10.0
Core2(conf-router_rip)#network 10.11.20.0
Core2(conf-router_rip)#show config
!
router rip
network 10.0.0.0
version 2
Core2(conf-router_rip)#
Core2(conf-router_rip)#end
00:12:24: %RPM0-P:CP %SYS-5-CONFIG_I: Configured from console by console
Core2#show ip rip database
Total number of routes in RIP database: 7
10.11.30.0/24
[120/1] via 10.11.20.1, 00:00:03, GigabitEthernet 2/31
10.300.10.0/24 directly connected,GigabitEthernet 2/42
10.200.10.0/24 directly connected,GigabitEthernet 2/41
10.11.20.0/24 directly connected,GigabitEthernet 2/31
10.11.10.0/24 directly connected,GigabitEthernet 2/11
10.0.0.0/8 auto-summary
192.168.1.0/24
[120/1] via 10.11.20.1, 00:00:03, GigabitEthernet 2/31
192.168.1.0/24 auto-summary
192.168.2.0/24
[120/1] via 10.11.20.1, 00:00:03, GigabitEthernet 2/31
192.168.2.0/24 auto-summary
Core2#
