822 | Quality of Service (QoS)
www.dell.com | support.dell.com
Figure 39-5. Displaying your Rate Policing Configuration
Configure Port-based Rate Limiting
Configure Port-based Rate Limiting is supported only on platform e
Rate limit egress traffic on an interface using the command rate limit from INTERFACE mode, as shown
in Figure 39-6. If the interface is a member of a VLAN, you may specify the VLAN for which egress
packets are rate limited.
Figure 39-6. Rate Limiting Egress Traffic
Display how your rate limiting configuration affects traffic using the keyword rate limit with the command
show interfaces, as shown in Figure 39-7.
FTOS Behavior: On the C-Series and S-Series, rate shaping is effectively rate limiting because of its smaller
buffer size.
FTOS#show interfaces gigabitEthernet 1/2 rate police
Rate police 300 (50) peak 800 (50)
Traffic Monitor 0: normal 300 (50) peak 800 (50)
Out of profile yellow 23386960 red 320605113
Traffic Monitor 1: normal NA peak NA
Out of profile yellow 0 red 0
Traffic Monitor 2: normal NA peak NA
Out of profile yellow 0 red 0
Traffic Monitor 3: normal NA peak NA
Out of profile yellow 0 red 0
Traffic Monitor 4: normal NA peak NA
Out of profile yellow 0 red 0
FTOS#config t
FTOS(conf)#interface gigabitethernet 1/0
FTOS(conf-if)#rate limit 100 40 peak 150 50
FTOS(conf-if)#end
FTOS#
