Dell Force10 S4810P - Relevant Management Objects

Link Layer Discovery Protocol (LLDP) | 659
Relevant Management Objects
FTOS supports all IEEE 802.1AB MIB objects.
• Table 30-7 lists the objects associated with received and transmitted TLVs.
• Table 30-8 lists the objects associated with the LLDP configuration on the local agent.
• Table 30-9 lists the objects associated with IEEE 802.1AB Organizationally Specific TLVs.
• Table 30-10 lists the objects associated with received and transmitted LLDP-MED TLVs.
F
TOS# debug lldp interface gigabitethernet 1/2 packet detail tx
F
TOS#1w1d19h : Transmit timer blew off for local interface Gi 1/2
1
w1d19h : Forming LLDP pkt to send out of interface Gi 1/2
1
w1d19h : TLV: Chassis ID, Len: 7, Subtype: Mac address (4), Value: 00:01:e8:0d:b6:d6
1
w1d19h : TLV: Port ID, Len: 20, Subtype: Interface name (5), Value: GigabitEthernet 1/2
1
w1d19h : TLV: TTL, Len: 2, Value: 120
1
w1d19h : TLV: SYS_DESC, Len: 207, Value:Dell Force10 Networks Real Time Operating System Software. Dell Force
10
O
perating System Version: 1.0. Dell Force10 Application Software Version: 8.3.11.4. Copyright (c)1999-2011 Dell In
c.
T
ime: Fri Oct 26 12:22:22 PDT 2007
1
w1d19h : TLV: SYSTEM CAPAB, Len: 4, Value: Existing: Repeater Bridge Router, Enabled: Repeater Bridge Router
1
w1d19h : TLV: ENDOFPDU, Len: 0
1
w1d19h : Sending LLDP pkt out of Gi 1/2 of length 270
1
w1d19h : Packet dump:
1
w1d19h : 01 80 c2 00 00 0e 00 01 e8 0d b7 3b 81 00 00 00
1
w1d19h : 88 cc 02 07 04 00 01 e8 0d b6 d6 04 14 05 47 69
1
w1d19h : 67 61 62 69 74 45 74 68 65 72 6e 65 74 20 31 2f
1
w1d19h : 32 06 02 00 78 0c cf 46 6f 72 63 65 31 30 20 4e
1
w1d19h : 65 74 77 6f 72 6b 73 20 52 65 61 6c 20 54 69 6d
1
w1d19h : 65 20 4f 70 65 72 61 74 69 6e 67 20 53 79 73 74
1
w1d19h : 65 6d 20 53 6f 66 74 77 61 72 65 2e 20 46 6f 72
1
w1d19h : 63 65 31 30 20 4f 70 65 72 61 74 69 6e 67 20 53
1
w1d19h : 79 73 74 65 6d 20 56 65 72 73 69 6f 6e 3a 20 31
1
w1d19h : 2e 30 2e 20 46 6f 72 63 65 31 30 20 41 70 70 6c
1
w1d19h : 69 63 61 74 69 6f 6e 20 53 6f 66 74 77 61 72 65
1
w1d19h : 20 56 65 72 73 69 6f 6e 3a 20 45 5f 4d 41 49 4e
1
w1d19h : 34 2e 37 2e 35 2e 32 37 36 2e 20 43 6f 70 79 72
1
w1d19h : 69 67 68 74 20 28 63 29 20 31 39 39 39 2d 42 75
1
w1d19h : 69 6c 64 20 54 69 6d 65 3a 20 46 72 69 20 4f 63
1
w1d19h : 74 20 32 36 20 31 32 3a 32 32 3a 32 32 20 50 44
1
w1d19h : 54 20 32 30 30 37 0e 04 00 16 00 16 00 00
1
w1d19h : LLDP frame sent out successfully of Gi 1/2
1
w1d19h : Started Transmit timer for Loc interface Gi 1/2 for time 30 sec
Source Address (LLDP Multicast)
802.1Q Header
Dell Force10 System Chassis ID
fnC0051mp
