Displaying FIP Snooping Information
Use the show commands in Table 18-1 to display information on FIP snooping.
Figure 18-3. show fip-snooping sessions Command Example
Table 18-1. Displaying FIP Snooping Information
Command Output
show fip-snooping sessions [interface vlan
vlan-id]
Displays information on FIP-snooped sessions on all VLANs or a specified
VLAN, including the ENode interface and MAC address, the FCF
interface and MAC address, VLAN ID, FCoE MAC address and FCoE
session ID number (FC-ID), worldwide node name (WWNN) and the
worldwide port name (WWPN).
show fip-snooping config Displays the FIP snooping status and configured FC-MAP values.
show fip-snooping enode
[enode-mac-address]
Displays information on the ENodes in FIP-snooped sessions, including
the ENode interface and MAC address, FCF MAC address, VLAN ID and
FC-ID.
show fip-snooping fcf [fcf-mac-address] Displays information on the FCFs in FIP-snooped sessions, including the
FCF interface and MAC address, FCF interface, VLAN ID, FC-MAP
value, FKA advertisement period, and number of ENodes connected.
clear fip-snooping database interface vlan
vlan-id {fcoe-mac-address | enode-mac-address
| fcf-mac-address}
Clears FIP snooping information on a VLAN for a specified FCoE MAC
address, ENode MAC address, or FCF MAC address, and removes the
corresponding ACLs generated by FIP snooping.
show fip-snooping statistics [interface vlan
vlan-id| interface port-type port/slot | interface
port-channel port-channel-number]
Displays statistics on the FIP packets snooped on all interfaces, including
VLANs, physical ports, and port channels.
clear fip-snooping statistics [interface vlan
vlan-id | interface port-type port/slot | interface
port-channel port-channel-number]
Clears the statistics on the FIP packets snooped on all VLANs, a specified
VLAN, or a specified port interface.
show fip-snooping system
Display information on the status of FIP snooping on the switch (enabled
or disabled), including the number of FCoE VLANs, FCFs, ENodes, and
currently active sessions.
show fip-snooping vlan
Display information on the FCoE VLANs on which FIP snooping is
enabled.
FTOS#show fip-snooping sessions
Enode MAC Enode Intf FCF MAC FCF Intf VLAN
aa:bb:cc:00:00:00 Te 0/42 aa:bb:cd:00:00:00 Te 0/43 100
aa:bb:cc:00:00:00 Te 0/42 aa:bb:cd:00:00:00 Te 0/43 100
aa:bb:cc:00:00:00 Te 0/42 aa:bb:cd:00:00:00 Te 0/43 100
aa:bb:cc:00:00:00 Te 0/42 aa:bb:cd:00:00:00 Te 0/43 100
aa:bb:cc:00:00:00 Te 0/42 aa:bb:cd:00:00:00 Te 0/43 100
FCoE MAC FC-ID Port WWPN Port WWNN
0e:fc:00:01:00:01 01:00:01 31:00:0e:fc:00:00:00:00 21:00:0e:fc:00:00:00:00
0e:fc:00:01:00:02 01:00:02 41:00:0e:fc:00:00:00:00 21:00:0e:fc:00:00:00:00
0e:fc:00:01:00:03 01:00:03 41:00:0e:fc:00:00:00:01 21:00:0e:fc:00:00:00:00
0e:fc:00:01:00:04 01:00:04 41:00:0e:fc:00:00:00:02 21:00:0e:fc:00:00:00:00
0e:fc:00:01:00:05 01:00:05 41:00:0e:fc:00:00:00:03 21:00:0e:fc:00:00:00:00
