MSDP Sample Configurations
The following figures show the running-configurations for the routers shown in figures Figure 31-5,
Figure 31-4, Figure 31-5, Figure 31-6.
Figure 31-22. MSDP Sample Configuration: R1 Running-config
ip multicast-routing
!
interface GigabitEthernet 1/1
ip pim sparse-mode
ip address 10.11.3.1/24
no shutdown
!
interface GigabitEthernet 1/2
ip address 10.11.2.1/24
no shutdown
!
interface GigabitEthernet 1/21
ip pim sparse-mode
ip address 10.11.1.12/24
no shutdown
!
interface Loopback 0
ip pim sparse-mode
ip address 192.168.0.1/32
no shutdown
!
router ospf 1
network 10.11.2.0/24 area 0
network 10.11.1.0/24 area 0
network 192.168.0.1/32 area 0
network 10.11.3.0/24 area 0
!
ip multicast-msdp
ip msdp peer 192.168.0.3 connect-source Loopback 0
!
ip pim rp-address 192.168.0.1 group-address 224.0.0.0/4
