The default option sets the CAM Profile as follows:
• L3 ACL (ipv4acl): 6
• L2 ACL(l2acl) : 5
• IPv6 L3 ACL (ipv6acl): 0
• L3 QoS (ipv4qos): 1
• L2 QoS (l2qos): 1
Save the new CAM settings to the startup-config (
write-mem or copy run start) then reload the system for the
new settings to take effect.
Assign an IPv6 Address to an Interface
IPv6 Addresses are supported on platforms c e s
Essentially IPv6 is enabled in FTOS simply by assigning IPv6 addresses to individual router interfaces.
IPv6 and IPv4 can be used together on a system, but be sure to differentiate that usage carefully. Use the
ipv6 address command to assign an IPv6 address to an interface.
When you configure IPv6 addresses on multiple interfaces (
ipv6 address command) and verify the
configuration (
show ipv6 interfaces command), the same link local (fe80) address is displayed for each IPv6
interface.
If the user attempts to configure more than two IPv6 addresses, the following error message appears:
Already configured maximum IPV6 addresses for this interface type
Command Syntax Command Mode Purpose
cam-acl { ipv6acl } CONFIGURATION Allocate space for IPV6 ACLs. Enter the CAM
profile name followed by the amount to be
allotted.
When not selecting the default option, you must
enter all of the profiles listed and a range for each.
The total space allocated must equal 13.
The ipv6acl range must be a factor of 2.
show cam-acl
EXEC
EXEC Privilege
Show the current CAM settings.
show cam-acl-egress
Provides information on FP groups allocated for
the egress acl.
You must allocate at least one group for L2ACL
and IPv4 ACL.
The total number of groups is 4.
