Applying an ETS Output Policy for a Priority Group to an
Interface
To apply ETS on egress port traffic, you must associate a priority group with an ETS output policy which
has scheduling and bandwidth configuration in a DCB output policy, and then apply the output policy to an
interface.
To apply ETS on egress port traffic, follow these steps:
Step Task Command Command Mode
1 Create a DCB output policy to associate an
ETS configuration with priority traffic.
Maximum: 32 alphanumeric characters.
dcb-output policy-name
CONFIGURATION
2 Enable the ETS configuration so that
scheduling and bandwidth allocation
configured in an ETS output policy or received
in a DCBx TLV from a peer can take effect on
an interface.
Default: ETS mode is on.
ets mode on
DCB OUTPUT POLICY
3 Associate the 802.1p priority traffic in a
priority group with the ETS configuration in a
QoS output policy.
priority-group group-name
qos-policy ets-policy-name
DCB OUTPUT POLICY
4 (Optional) Enter a text description of the output
policy.
Maximum: 32 characters.
description text
DCB OUTPUT POLICY
5 Repeat Steps 1 to 4 to configure all remaining ETS priority groups with an ETS output policy.
6 Exit DCB Output Policy Configuration mode.
exit
DCB OUTPUT POLICY
7 Enter INTERFACE Configuration mode.
interface type slot/port
CONFIGURATION
8 Apply the output policy with the ETS
configuration to an egress interface.
dcb-policy output
policy-name
INTERFACE
