Dell Force10 S4810P - Microcode

Content Addressable Memory (CAM) | 275
The size of CAM partitions is measured in entries. Table 11-1 shows the number of entries available in
each partition for all CAM profiles. The total CAM space is finite, therefore adding entries to one region
necessarily decreases the number available to other regions.
Table 11-2. CAM entries per partition
Microcode
Microcode is a compiled set of instructions for a CPU. On Dell Force10 systems, the microcode controls
how packets are handled.
There is a default microcode, and several other microcodes are available, so that you can adjust packet
handling according to your application. Specifying a microcode is mandatory when selecting a CAM
profile (though you are not required to change it).
ipv4-64k-ipv6 Provides IPv6 functionality; an alternate to ipv6-extacl that redistributes CAM space from the IPv4FIB
to IPv4Flow and IPv6FIB.
Available Microcodes: ipv6-extacl
Profile
Partition L2FIB L2ACL IPv4FIB IPv4ACL IPv4Flow EgL2ACL EgIPv4ACL Reserved IPv6FIB IPv6ACL IPv6Flow EgIPv6ACL
Default
32K 2K 256K 12K 24K 1K 1K 8K 0 0 0 0
eg-default
32K 2K 512K 12K 24K 1K 1K 8K 32K 3K 4K 1K
ipv4-320k
32K 2K 320K 12K 12K 1K 1K 4K 0 0 0 0
pv4-egacl-16k
32K 2K 192K 8K 24K 0 16K 8K 0 0 0 0
ipv6-extacl
32K 2K 192K 12K 8K 1K 1K 2K 6K 3K 4K 2K
l2-ipv4-inacl
32K 33K 64K 27K 8K 2K 2K 2K 0 0 0 0
unified-default
32K 3K 192K 9K 8K 2K 2K 2K 6K 2K 4K 2K
ipv4-64k-ipv6
32K 2K 64K 12K 24K 1K 1K 8K 16K 3K 4K 1K
Note: Not all CAM profiles and microcodes are available for all systems. Refer to the Command Line
Interface Reference Guide for details regarding available profiles for each system.
Table 11-1. CAM Profile Descriptions
CAM Profile Description
