472 | Interfaces
www.dell.com | support.dell.com
Interface Types
View Basic Interface Information
The user has several options for viewing interface status and configuration parameters. The show interfaces
command in EXEC mode will list all configurable interfaces on the chassis and has options to display the
interface status, IP and MAC addresses, and multiple counters for the amount and type of traffic passing
through the interface. If a port channel interface is configured, the
show interfaces command can list the
interfaces configured in the port channel.
The following example displays the configuration and status information for one interface.
FTOS#show interfaces tengigabitethernet 1/0
TenGigabitEthernet 1/0 is up, line protocol is up
Hardware is Force10Eth, address is 00:01:e8:05:f3:6a
Current address is 00:01:e8:05:f3:6a
Pluggable media present, XFP type is 10GBASE-LR.
Medium is MultiRate, Wavelength is 1310nm
XFP receive power reading is -3.7685
Interface index is 67436603
Internet address is 65.113.24.238/28
MTU 1554 bytes, IP MTU 1500 bytes
LineSpeed 10000 Mbit, Mode full duplex, Master
ARP type: ARPA, ARP Timeout 04:00:00
Last clearing of "show interface" counters 00:09:54
Queueing strategy: fifo
Interface Type
Modes
Possible Default Mode
Requires
Creation Default State
Physical L2, L3 Unset No Shutdown (disabled)
Management N/A N/A No No Shutdown (enabled)
Loopback L3 L3 Yes No Shutdown (enabled)
Null N/A N/A No Enabled
Port Channel L2, L3 L3 Yes Shutdown (disabled)
VLAN L2, L3 L2 Yes (except
default)
L2 - No Shutdown (enabled)
L3 - Shutdown (disabled)
Note: To end output from the system, such as the output from the show interfaces command, enter
CTRL+C and FTOS will return to the command prompt.
Note: The CLI output may be incorrectly displayed as 0 (zero) for the Rx/Tx power values. Perform an
SNMP query to obtain the correct power information.
