Dell Force10 S4810P - MSTP Sample Configurations

702 | Multiple Spanning Tree Protocol (MSTP)
www.dell.com | support.dell.com
MSTP Sample Configurations
The running-configurations in Figure 32-10, Figure 32-11, and Figure 32-11 support the topology shown
in Figure 32-9. The configurations are from FTOS systems. An S50 system using SFTOS, configured as
shown Figure 32-13, could be substituted for an FTOS router in this sample following topology and MSTP
would function as designed.
Figure 32-9. MSTP with Three VLANs Mapped to Two Spanning Tree Instances
R1
R2
R3
1/2
3/1
3/2
1/3
2/1
2/3
root
Forwarding
Blocking
