846 | Routing Information Protocol (RIP)
www.dell.com | support.dell.com
Figure 40-2. show ip rip database Command Example (Partial)
To disable RIP globally, use the no router rip command in the CONFIGURATION mode.
Configure RIP on interfaces
When you enable RIP globally on the system, interfaces meeting certain conditions start receiving RIP
routes. By default, interfaces that are enabled and configured with an IP address in the same subnet as the
RIP network address receive RIPv1 and RIPv2 routes and send RIPv1 routes.
Assign IP addresses to interfaces that are part of the same subnet as the RIP network identified in the
network command syntax.
Control RIP routing updates
By default, RIP broadcasts routing information out all enabled interfaces, but you can configure RIP to
send or to block RIP routing information, either from a specific IP address or a specific interface. To
control which devices or interfaces receive routing updates, you must configure a direct update to one
router and configure interfaces to block RIP updates from other sources.
FTOS#show ip rip database
Total number of routes in RIP database: 978
160.160.0.0/16
[120/1] via 29.10.10.12, 00:00:26, Fa 0/0
160.160.0.0/16 auto-summary
2.0.0.0/8
[120/1] via 29.10.10.12, 00:01:22, Fa 0/0
2.0.0.0/8 auto-summary
4.0.0.0/8
[120/1] via 29.10.10.12, 00:01:22, Fa 0/0
4.0.0.0/8 auto-summary
8.0.0.0/8
[120/1] via 29.10.10.12, 00:00:26, Fa 0/0
8.0.0.0/8 auto-summary
12.0.0.0/8
[120/1] via 29.10.10.12, 00:00:26, Fa 0/0
12.0.0.0/8 auto-summary
20.0.0.0/8
[120/1] via 29.10.10.12, 00:00:26, Fa 0/0
20.0.0.0/8 auto-summary
29.10.10.0/24 directly connected,Fa 0/0
29.0.0.0/8 auto-summary
31.0.0.0/8
[120/1] via 29.10.10.12, 00:00:26, Fa 0/0
31.0.0.0/8 auto-summary
192.162.2.0/24
[120/1] via 29.10.10.12, 00:01:21, Fa 0/0
192.162.2.0/24 auto-summary
192.161.1.0/24
[120/1] via 29.10.10.12, 00:00:27, Fa 0/0
192.161.1.0/24 auto-summary
192.162.3.0/24
[120/1] via 29.10.10.12, 00:01:22, Fa 0/0
192.162.3.0/24 auto-summary
