Implementation Information
• The FTOS implementation of PVST+ is based on IEEE Standard 802.1d.
• The FTOS implementation of PVST+ uses IEEE 802.1s costs as the default costs (Table 38-2). Other
implementations use IEEE 802.1d costs as the default costs if you are using Dell Force10 systems in a
multi-vendor network, verify that the costs are values you intended.
• You must allocate at least the default minimum amount of Layer 2 ACL CAM space when employing
PVST+ on the E-Series. See Configure Ingress Layer 2 ACL Sub-partitions on page 287.
• On the C-Series and S-Series, you can enable PVST+ on 254 VLANs. To set up VLANs, see
Chapter 53, Virtual LANs (VLAN).
Configure Per-VLAN Spanning Tree Plus
Configuring PVST+ is a four-step process:
1. Configure interfaces for Layer 2.
2. Place the interfaces in VLANs.
3. Enable PVST+. See page 807.
4. Optionally, for load balancing, select a non-default bridge-priority for a VLAN. See page 807.
Related Configuration Tasks
• Modify Global PVST+ Parameters on page 809
• Modify Interface PVST+ Parameters on page 810
• Configure an EdgePort on page 811
• Flush MAC Addresses after a Topology Change on page 701
• Preventing Network Disruptions with BPDU Guard on page 1011
• SNMP Traps for Root Elections and Topology Changes on page 1016
• Configuring Spanning Trees as Hitless on page 1017
• PVST+ in Multi-vendor Networks on page 812
• PVST+ Extended System ID on page 812
• PVST+ Sample Configurations on page 813
Multiple Spanning Tree Protocol
(MSTP)
802.1s
Per-VLAN Spanning Tree Plus
(PVST+)
Third Party
Table 38-1. FTOS Supported Spanning Tree Protocols
Dell Force10 Term IEEE Specification
