Quality of Service (QoS) | 839
Display WRED Drop Statistics
Display the number of packets FTOS dropped by WRED Profile using the command show qos statistics
from EXEC Privilege mode.
Figure 39-16. show qos statistics Command Example (E-Series)
Figure 39-17. show qos statistics Command Example (S4810)
FTOS Behavior: The C-Series fetches the per-queue packet count via class-maps. The count is the number of
packets matching the ACL entries in class-map. Every time the class-map or policy-map is modified, the ACL
entries are re-written to the Forwarding Processor, and the queue statistics are cleared. This behavior is different
from the E-Series. The E-Series fetches the packet count directly from counters at each queue, which allows
queue statistics to persist until explicitly cleared via the CLI.
FTOS#show qos statistics wred-profile
Interface Gi 5/11
Queue# Drop-statistic WRED-name Min Max Dropped Pkts
0 Green WRED1 10 100 51623
Yellow WRED2 20 100 51300
Out of Profile 0
1 Green WRED1 10 100 52082
Yellow WRED2 20 100 51004
Out of Profile 0
2 Green WRED1 10 100 50567
Yellow WRED2 20 100 49965
Out of Profile 0
3 Green WRED1 10 100 50477
Yellow WRED2 20 100 49815
Out of Profile 0
4 Green WRED1 10 100 50695
Yellow WRED2 20 100 49476
Out of Profile 0
5 Green WRED1 10 100 50245
Yellow WRED2 20 100 49535
Out of Profile 0
6 Green WRED1 10 100 50033
Yellow WRED2 20 100 49595
Out of Profile 0
7 Green WRED1 10 100 50474
Yellow WRED2 20 100 49522
Out of Profile 0
FTOS#
FTOS#show qos statistics wred-profile
Interface Te 0/0
Drop-statistic WRED-name Dropped Pkts
Green WRED1 51623
Yellow WRED2 51300
Out of Profile 0
FTOS#
