660 | Link Layer Discovery Protocol (LLDP)
www.dell.com | support.dell.com
Table 30-7. LLDP Configuration MIB Objects
MIB Object Category LLDP Variable LLDP MIB Object Description
LLDP Configuration adminStatus lldpPortConfigAdminStatus Whether the local LLDP agent is
enabled for transmit, receive, or both
msgTxHold lldpMessageTxHoldMultiplier Multiplier value
msgTxInterval lldpMessageTxInterval Transmit Interval value
rxInfoTTL lldpRxInfoTTL Time to Live for received TLVs
txInfoTTL lldpTxInfoTTL Time to Live for transmitted TLVs
Basic TLV Selection mibBasicTLVsTxEnable lldpPortConfigTLVsTxEnable Indicates which management TLVs
are enabled for system ports
mibMgmtAddrInstanceT
xEnable
lldpManAddrPortsTxEnable The management addresses defined
for the system and and the ports
through which they are enabled for
transmission
LLDP Statistics statsAgeoutsTotal lldpStatsRxPortAgeoutsTotal Total number of times that a
neighbors information is deleted on
the local system due to an rxInfoTTL
timer expiration
statsFramesDiscardedTot
al
lldpStatsRxPortFramesDiscar
dedTotal
Total number of LLDP frames
received then discarded
statsFramesInErrorsTotal lldpStatsRxPortFramesErrors Total number of LLDP frames
received on a port with errors
statsFramesInTotal lldpStatsRxPortFramesTotal Total number of LLDP frames
received through the port
statsFramesOutTotal lldpStatsTxPortFramesTotal Total number of LLDP frames
transmitted through the port
statsTLVsDiscardedTotal lldpStatsRxPortTLVsDiscarde
dTotal
Total number of TLVs received then
discarded
statsTLVsUnrecognizedT
otal
lldpStatsRxPortTLVsUnrecog
nizedTotal
Total number of all TLVs the local
agent does not recognize
Table 30-8. LLDP System MIB Objects
TLV Type TLV Name TLV Variable System LLDP MIB Object
1 Chassis ID chassis ID subtype Local lldpLocChassisIdSubtype
Remote lldpRemChassisIdSubtype
chassid ID Local lldpLocChassisId
Remote lldpRemChassisId
