Figure 9-15. Command example: show running-config bgp
Configure AS4 Number Representations
Enable one type of AS Number Representation: ASPLAIN, ASDOT+, or ASDOT.
• ASPLAIN is the method FTOS has used for all previous FTOS versions. It remains the default method
with FTOS 8.2.1.0 and later. With the ASPLAIN notation, a 32 bit binary AS number is translated into
a decimal value.
• ASDOT+ representation splits the full binary 4-byte AS number into two words of 16 bits separated by
a decimal point (.): <high-order 16 bit value>.<low-order 16 bit value>.
• ASDOT representation combines the ASPLAIN and ASDOT+ representations. AS Numbers less than
65536 appear in integer format (asplain); AS Numbers equal to or greater than 65536 appear using the
decimal method (asdot+). For example, the AS Number 65526 appears as 65526, and the AS Number
65546 appears as 1.10.
Note: The ASDOT and ASDOT+ representations are supported only in conjunction with the 4-Byte AS
Numbers feature. If 4-Byte AS Numbers are not implemented, only ASPLAIN representation is supported.
R2#show running-config bgp
!
router bgp 65123
bgp router-id 192.168.10.2
network 10.10.21.0/24
network 10.10.32.0/24
network 100.10.92.0/24
network 192.168.10.0/24
bgp four-octet-as-support
neighbor 10.10.21.1 remote-as 65123
neighbor 10.10.21.1 filter-list ISP1in
neighbor 10.10.21.1 no shutdown
neighbor 10.10.32.3 remote-as 65123
neighbor 10.10.32.3 no shutdown
neighbor 100.10.92.9 remote-as 65192
neighbor 100.10.92.9 no shutdown
neighbor 192.168.10.1 remote-as 65123
neighbor 192.168.10.1 update-source Loopback 0
neighbor 192.168.10.1 no shutdown
neighbor 192.168.12.2 remote-as 65123
neighbor 192.168.12.2 update-source Loopback 0
neighbor 192.168.12.2 no shutdown
R2#
