Content Addressable Memory (CAM) | 283

Ipv4Qos : 2

L2Qos : 2

L2PT : 1

IpMacAcl : 2

VmanQos : 0

VmanDualQos : 0

EcfmAcl : 0

-- Line card 0 --

Current Settings(in block sizes)

L2Acl : 2

Ipv4Acl : 2

Ipv6Acl : 2

Ipv4Qos : 2

L2Qos : 2

L2PT : 1

IpMacAcl : 2

VmanQos : 0

VmanDualQos : 0

EcfmAcl : 0

-- Line card 6 --

Current Settings(in block sizes)

L2Acl : 2

Ipv4Acl : 2

Ipv6Acl : 2

Ipv4Qos : 2

L2Qos : 2

L2PT : 1

IpMacAcl : 2

VmanQos : 0

VmanDualQos : 0

EcfmAcl : 0

The default values for the show cam-acl command for the are:

FTOS#show cam-acl

-- Chassis Cam ACL --

Current Settings(in block sizes)

L2Acl : 4

Ipv4Acl : 4

Ipv6Acl : 0

Ipv4Qos : 2

L2Qos : 1

L2PT : 0

IpMacAcl : 0

VmanQos : 0

VmanDualQos : 0

EcfmAcl : 0

FcoeAcl : 0

iscsiOptAcl : 2

-- Stack unit 0 --

Current Settings(in block sizes)
