664 | Link Layer Discovery Protocol (LLDP)

www.dell.com | support.dell.com

4 Extended Power via

MDI

Power Device Type Local lldpXMedLocXPoEDeviceTyp

Remote lldpXMedRemXPoEDeviceTy

Power Source Local lldpXMedLocXPoEPSEPower

Source,

lldpXMedLocXPoEPDPowerS

ource

Remote lldpXMedRemXPoEPSEPowe

rSource,

lldpXMedRemXPoEPDPower

Source

Power Priority Local lldpXMedLocXPoEPDPowerP

riority,

lldpXMedLocXPoEPSEPortP

DPriority

Remote lldpXMedRemXPoEPSEPowe

rPriority,

lldpXMedRemXPoEPDPower

Priority

Power Value Local lldpXMedLocXPoEPSEPortPo

werAv,

lldpXMedLocXPoEPDPower

Req

Remote lldpXMedRemXPoEPSEPowe

rAv,

lldpXMedRemXPoEPDPower

Req

Table 30-10. LLDP-MED System MIB Objects

TLV Sub-Type TLV Name TLV Variable System LLDP-MED MIB Object
