670 | Multicast Source Discovery Protocol (MSDP)
www.dell.com | support.dell.com
Figure 31-5. Configuring PIM in Multiple Routing Domains
AS 100
AS 200
RP1
RP2
R1
R2
R3
R4
1/1
1/21
2/11
2/31
3/21
3/41
4/31
4/1
1/2
PC 2
Source: 239.0.0.1
PC 3
Receiver: 239.0.0.1
2/1
PC 2
Receiver: 239.0.0.1
ip multicast-routing
!
ip pim rp-address 192.168.0.1 group-address 224.0.0.0/4
ip multicast routing
!
ip pim rp-address 192.168.0.1 group-address 224.0.0.0/4
P
I
M
+
I
G
M
P
ip multicast-routing
!
ip pim rp-address 192.168.0.3 group-address 224.0.0.0/4
P
I
M
+
I
G
M
P
ip multicast-routing
!
ip pim rp-address 192.168.0.3 group-address 224.0.0.0/4
