804 | Private VLANs (PVLAN)
www.dell.com | support.dell.com
Figure 37-8. Example running-config Output of PVLAN Configuration from S50V
!
interface GigabitEthernet 0/3
no ip address
switchport
switchport mode private-vlan promiscuous
no shutdown
!
interface GigabitEthernet 0/4
no ip address
switchport
switchport mode private-vlan host
no shutdown
!
interface GigabitEthernet 0/5
no ip address
switchport
switchport mode private-vlan host
no shutdown
!
interface GigabitEthernet 0/6
no ip address
switchport
switchport mode private-vlan host
no shutdown
!
interface GigabitEthernet 0/25
no ip address
switchport
switchport mode private-vlan trunk
no shutdown
!
interface Vlan 4000
private-vlan mode primary
private-vlan mapping secondary-vlan 4001-4003
no ip address
tagged GigabitEthernet 0/3,25
no shutdown
!
interface Vlan 4001
private-vlan mode community
