960 | Simple Network Management Protocol (SNMP)
www.dell.com | support.dell.com
Dell Force10 provides additional MIB Objects to view copy statistics. These are provided in Table 46-5.
To obtain a value for any of the MIB Objects in Table 46-5:
Figure 46-14 and Figure 46-15 are examples of using the command
snmpget to obtain a MIB object value.
These examples assume that:
• the server OS is UNIX
• you are using SNMP version 2c
• the community name is public, and
• the file f10-copy-config.mib is in the current directory.
Table 46-5. MIB Objects for Copying Configuration Files via SNMP
MIB Object OID Values Description
copyState .1.3.6.1.4.1.6027.3.5.1.1.1.1.11 1= running
2 = successful
3 = failed
Specifies the state of the copy
operation.
copyTimeStarted .1.3.6.1.4.1.6027.3.5.1.1.1.1.12 Time value Specifies the point in the up-time clock
that the copy operation started.
copyTimeCompleted .1.3.6.1.4.1.6027.3.5.1.1.1.1.13 Time value Specifies the point in the up-time clock
that the copy operation completed.
copyFailCause .1.3.6.1.4.1.6027.3.5.1.1.1.1.14 1 = bad file name
2 = copy in progress
3 = disk full
4 = file exists
5 = file not found
6 = timeout
7 = unknown
Specifies the reason the copy request
failed.
copyEntryRowStatus .1.3.6.1.4.1.6027.3.5.1.1.1.1.15 Row status Specifies the state of the copy
operation. Uses CreateAndGo when
you are performing the copy. The state
is set to active when the copy is
completed.
Step Task
1 Get a copy-config MIB object value.
snmpset -v 2c -c public -m ./f10-copy-config.mib force10system-ip-address [OID.index | mib-object.index]
• index is the index value used in the snmpset command used to complete the copy operation.
Note: You can use the entire OID rather than the object name. Use the form: OID.index, as shown in Figure 46-15.
Note: In UNIX, enter the command snmpset for help using this command.
