108 Upgrade and Maintenance Manual TX1320 M1
Power supply
6.1 Standard power supply unit
6.1.1 Replacing the standard power supply unit
6.1.1.1 Preliminary steps
Before replacing the standard PSU, perform the following steps:
I You are advised to perform this routine with the server in a horizontal
position.
Ê Disable BitLocker functionality as described in section "Disabling BitLocker
functionality" on page 73.
Ê Locate the defective server as described in section "Locating the defective
server" on page 44.
Ê Shut down the server as described in section "Shutting down the server" on
page 52.
Ê Disconnect the AC power cord from the system.
Ê Remove the server cover as described in section "Opening the server" on
page 55.
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools:
tool-less (preliminary and concluding steps)
Phillips PH2 / (+) No. 2 screw drive (replacing the PSU)

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
