Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

318 Upgrade and Maintenance Manual TX1320 M1
Cables
15.1 Cabling overview
15.1.1 Overview of used cables
No. Name Number Routing 2.5"
HDD
model
3.5"
HDD
model
C1
Front panel
connector / USB 3.0
cable
T26139-Y4015-V4
from front panel
module to system
board
oo
C2 Power cable
T26139-Y4012-
V501
from all drives to
system board
oo
C3 SATA cable
T26139-Y3928-
V205
Alternative:
T26139-Y4028-
V103
from optical disk drive
to system board
oo
C4 SAS / SATA cable
T26139-Y3963-
V113
from 2.5-inch HDD
backplane to system
board
o
C5 SATA Y-cable
T26139-Y3964-
V201
from 3.5-inch HDDs
to system board
o
C7 IF FBU installed:
FBU adapter cable
T26139-Y4032-V1/-
V2
from FBU to RAID
controller
oo
C8 T26139-Y4040-V2 Mini SAS to
extension board
oo
C9 CBL_SMB_1xBP T26139-Y4015-
V603
C10 T26139-Y4011-V4 Fan adapter
Table 6: List of used cables

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
