Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

TX1320 M1 Upgrade and Maintenance Manual 327
Appendix
16.3.1.2 Onboard settings
Figure 205: Jumper
Setting Description
Default Password skip disabled and recovery BIOS disabled
RCVR Recovery BIOS enabled
When the recovery BIOS is applied on a system board, the
password set by customers disappears from system board.
PWD SKIP Password delete enabled
The password is deleted and the default BIOS settings are
applied after “PWD SKIP” jumper was set once.
Default
RCVR
HDD ACTIVITY
TPM
Slot 1 PCIe x1
Jumper
Battery
SATA6 SATA5
Slot 3 PCIe x8
Slot 2 PCIe x4

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
