Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

326 Upgrade and Maintenance Manual TX1320 M1
Appendix
No. Print Description
1 PWR1 ATX power supply connector
2 FAN4 SYS Connector for system fan
3SATA POWER
Power distribution for SAS / SATA backplanes and
accessible drives
4 PC2009 Power management connector
5 FRONTPANEL Front panel
6 P30 Power supply connector
7 USB FRONT Connector for front USB
8 FAN3 SYS Connector for system fan
9 FAN1 SYS Connector for system fan
10 SATA MLC1
SATA MLC connector for 3.5-inch HDD
configurations
11 FAN2 SYS Connector for system fan
12 USB1 AUX USB 2.0 for Front panel
13 USB1 DAT USB 2.0 connector for accessible backup drive
14 INTR Intrusion switch cable connector
15 UFM Connector for USB Flash Module (UFM)
16 SATA 5 SATA 5 connector
17 SATA 6 SATA 6 connector
18 TPM Connector for Trusted Platform Module (TPM)
19 HDD ACTIVITY (not used)
20 Micro SD

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
