62 Upgrade and Maintenance Manual TX1320 M1
Basic hardware procedures
4.5 Closing the front cage
4.5.1 3.5-inch hard disk drive version
Figure 18: Closing the front cage
Ê Carefully close the front cage (1).
V CAUTION!
Ensure that none of the cables are strained or trapped!
Ê Connect all loose cables to the system board again.
Ê Tighten the captive knurled thumb screw on the front cage (2).
햳
햲

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
