Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

TX1320 M1 Upgrade and Maintenance Manual 159
System fan and HDD fan
8.2 Replacing the HDD fan module
8.2.1 Replacing the HDD fan module for 3.5-inch version
8.2.1.1 Preliminary steps
Before replacing the HDD fan module, perform the following steps:
Ê Locate the defective server as described in section "Locating the defective
server" on page 44.
Ê Shut down the defective server as described in section "Shutting down the
server" on page 52.
Ê Disconnect the AC power cord from the system.
Ê Remove the server cover as described in section "Opening the server" on
page 55.
Ê Open the front cage as described in section "Opening the front cage" on
page 60.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
