Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

252 Upgrade and Maintenance Manual TX1320 M1
Accessible drives
12.3 Backup drive
12.3.1 Installing backup drive
12.3.1.1 Preliminary steps
Before installing an accessible drive, perform the following steps:
Ê Disable BitLocker functionality as described in section "Disabling BitLocker
functionality" on page 73.
Ê Shut down the server as described in section "Shutting down the server" on
page 52.
Ê Disconnect the AC power cord from the system.
Ê Remove the server cover as described in section "Opening the server" on
page 55.
12.3.1.2 Removing the backup drive cover
Ê Open the drive cover of the side / top cover as described in section
"Removing the drive cover" on page 58.
Upgrade and Repair Unit
(URU)
Hardware: 10minutes
Tools:
Preliminary and concluding steps: tool-less
Removing accessible drives: Phillips PH2 / (+) No. 2 screw driver

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
