Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

250 Upgrade and Maintenance Manual TX1320 M1
Accessible drives
12.2.3 Replacing an optical disk drive (ODD)
12.2.3.1 Preliminary steps
Before installing an accessible drive, perform the following steps:
Ê Disable BitLocker functionality as described in section "Disabling BitLocker
functionality" on page 73.
Ê Remove optical disk media from the drive.
Ê Shut down the server as described in section "Shutting down the server" on
page 52.
Ê Disconnect the AC power cord from the system.
Ê Remove the server cover as described in section "Opening the server" on
page 55.
12.2.3.2 Replacing the optical disk drive
Ê Remove the defective ODD as described in section "Removing an optical
disk drive (ODD)" on page 245.
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools:
Preliminary and concluding steps: Slotted screw driver (only for
removing the optical disk drive filler cover)
Installing accessible drives: tool-less

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
