Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

214 Upgrade and Maintenance Manual TX1320 M1
Expansion cards and backup units
9.4.2.3 Replacing SFP+ transceiver modules
For Fiber Channel over Ethernet (FCoE) configurations, the ethernet server
adapter is equipped with one or two SFP+ (small form-factor pluggable)
transceiver modules.
Removing SFP+ transceiver modules
Ê Remove the defective SFP+ transceiver module(s) as described in section
"Removing an SFP+ transceiver module" on page 212.
Installing SFP+ transceiver modules
Ê Unpack the new SFP+ transceiver module.
Ê Verify that the new SFP+ transceiver module is the same type of transceiver
you are replacing.
Ê Install the replacement SFP+ transceiver module(s) as described in section
"Installing SFP+ transceiver modules" on page 207.
Ê Inform the customer about changed WWN and MAC addresses.
I By replacing SFP+ transceiver modules, WWN (World Wide Name)
and MAC (Media Access Control) addresses will change.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
