236 Upgrade and Maintenance Manual TX1320 M1
Accessible drives
12.1 Basic procedure
Mounting order for accessible drives
PRIMERGY TX1320 M1 server offers a 5.25-inch slimline SATA optical drive
bay and 2.5-inch USB backup drive bay:
Figure 132: Accessible drives mounting order
Accessible drive Max. #
3.5-inch bay ODD 1
5.25-inch bay2 Backup drive 1
Table 5: Accessible drive mounting sequence

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
