12.4.1.2 Removing the backup drive filler cover
Figure 155: Removing the backup drive filler cover
Ê Hold the backup drive filler cover by its two handle recesses (1) and pull it
out of the installation bay (2).
V CAUTION!
Save the backup drive filler cover for future use.
Always replace dummy modules into unused drive bays to comply with
applicable EMC regulations and satisfy cooling requirements.
/
/
