Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

122 Upgrade and Maintenance Manual TX1320 M1
Hard disk drives / solid state drives
7.2.3 Removing 2.5-inch HDD / SSD modules
7.2.3.1 Preliminary steps
Before removing a 2.5-inch HDD / SSD module, perform the following steps:
Ê Ensure that the HDD / SSD module to be removed is not combined into a
RAID array. If the drive is part of a RAID array, you first need to delete the
array using ServerView RAID Manager.
V CAUTION!
All data on all HDDs / SSDs in the array will be lost! Be sure to back
up your data before deleting a RAID array.
I For further information, please refer to the "ServerView Suite RAID
Management" user guide, available online at
http://manuals.ts.fujitsu.com (EMEA market) or
http://jp.fujitsu.com/platform/server/primergy/manual/ (Japanese
market) or from the ServerView Suite DVD supplied with your
PRIMERGY server.
Ê Remove the hard disk drive cover as described in section "Removing the
hard disk drive cover" on page 59.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
