Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

TX1320 M1 Upgrade and Maintenance Manual 207
Expansion cards and backup units
9.4.2 Handling SFP+ transceiver modules
For Fiber Channel over Ethernet (FCoE) configurations, the Ethernet server
adapter is equipped with one or two SFP+ (small form-factor pluggable)
transceiver modules.
9.4.2.1 Installing SFP+ transceiver modules
Preparing the SFP+ transceiver module
Figure 108: Removing the protective optical port plug
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
